Custom 5-Point Sail Shade Structures That Cover More Ground
Your visitors notice when a shade structure does something different. The USA Shade 5-Point Sail Shade stands out from standard canopies with five columns set at varying heights, creating a formable fabric top that can be shaped into a distinctive, site-specific look. Parks, schools, recreation facilities, and commercial properties use it where maximum coverage and a visually compelling design both matter.
Instead of a fixed, uniform canopy, your property gets a tensioned sail with five anchor points that gives you more control over the final form of the structure than a three or four point alternative. The result is a shade solution that covers more ground, adapts to irregular spaces, and looks like it was designed specifically for the site — because it was.
Supply-A-City is an authorized USA Shade and Fabric Structures distributor. All products are manufactured in the USA and backed by a 10-year structural warranty on steel and a 10-year limited fabric warranty.
Design Your Custom 5-Point Shade Sail from Five Anchor Points
With five columns at varying heights and sides reaching up to 40 feet, the 5-Point Sail offers more shaping flexibility than any other sail in the USA Shade lineup. The formable fabric top means the structure can take on a unique profile rather than a predictable geometric shape, making it a strong choice for properties where the shade structure is as much a design feature as a functional one.
When multiple sails are needed, joined configurations are available for expanded coverage across larger spaces. Wind load engineering is handled as part of the quote process, so your structure is built for the specific demands of your location. If your project is better suited to a smaller footprint, the 3-Point Sail and 4-Point Hypar Sail are worth comparing during your quote.
Fabric Options for Any Climate and Code Requirement
Shadesure™ is the standard fabric option, available in 20 colors with a wide range of shade factors and UV blocking levels. Colourshade® FR is a fire-rated fabric approved by California's Division of the State Architect (DSA), making it the correct specification for California school projects and other DSA-regulated installations. It is available in 7 colors.
Steel post colors are available in Black, Cobalt, Blue, Forest Green, Red, Yellow, Dark Brown, Light Ivory, White, and Tele-Gray. Steel finish options include super durable TGIC powder coat, Zinc Rich Coastal primer and powder coat, hot dip galvanizing, and combinations of galvanizing with powder coat or wet paint.
Technical Specifications
-
Frame material: Flo-coat pre-galvanized steel (smaller structures) / Black steel (larger structures)
-
Maximum side length: Up to 40 feet per side
-
Configuration: 5-point tensioned sail with columns at varying heights; joined multi-sail systems available
-
Fabric options: Shadesure™ (20 colors) / Colourshade® FR — fire-rated, DSA approved (7 colors)
-
Steel finishes: TGIC powder coat, Zinc Rich Coastal primer and powder coat, hot dip galvanizing, galvanizing with powder coat or wet paint
-
Post colors: Black, Cobalt, Blue, Forest Green, Red, Yellow, Dark Brown, Light Ivory, White, Tele-Gray
-
Warranty: 10-year structural on steel; 10-year limited on fabric. See full warranty page for details.
-
Availability: Made to order. Contact us for lead time.
Supply-A-City is an authorized USA Shade and Fabric Structures distributor serving parks departments, school districts, property managers, and facilities directors across the United States.
