Is a row of single hoops eating your sidewalk while bikes still end up locked to parking meters and trees?
Instead, one 63 3/4 inch rack parks up to 7 bikes on 5 loops, standing on just two base plates bolted to your concrete.
That replaces 4 two-bike hoops, so your crew drills fewer anchors and mows and plows around fewer posts.
As your authorized distributor, Supply-A-City delivers this rack with free shipping and expert support.
Up to 7 Bikes | 5 Loops | 63 3/4" Wide | 35" Tall | 1 7/8" Steel Tube | Surface Mount | 8 Colors | 5-Year Warranty
The rack is 63 3/4 inches long and 35 inches tall, so 7 bikes park along about 5 1/3 feet of curb or storefront.
The loops sit 10 1/2 inches apart, and the bottom of each loop clears the ground by 4 1/2 inches, so your crew can get a broom or blower underneath.
Riders park from both sides. Leave a bike's length of clear space on each side, out of the path your pedestrians need.
The frame is one length of 1 7/8 inch steel tube bent into 5 loops, with a 4 inch base plate at each end that bolts to your slab.
It is powder coated in your choice of 8 colors. If the finish fails early, the 5-year warranty makes it a claim we handle, not a repaint you budget for.
Your installer picks the anchors from the drawing under the Resources tab.
| 7 Bike Serpentine Rack Specifications (BRK534S) | |
| Capacity | Up to 7 bikes on 5 loops |
| Overall size | 63 3/4" long x 35" tall |
| Gap between loops | 10 1/2" |
| Ground clearance | 4 1/2" under each lower loop |
| Tube | 1 7/8" O.D. steel |
| Mounting | Surface mount, 4" base plate at each end |
| Finish | Powder coat in Blue, Sand, Green, Black, Brown, Purple, Red or Yellow |
| Weight | 43 lbs |
| Warranty | 5 years |
Every color is built to order and ships in about 14 to 24 business days. Each rack clears our $500 free shipping threshold, so even one ships free to the lower 48 states.
Need an inground rack or a shorter run? Compare every style in our bike rack collection.
Equipping a downtown district or a campus? Call (833) 746-7688 or email info@supplyacity.com for project quantities.
